Mechanical & Structural
• Structure: Heavy-duty MS fabricated structure
• Columns & Beams: ISMB / ISMC steel sections
• Platform: MS chequered / deck plate with anti-skid finish
• Surface Treatment: Shot blasting + epoxy / PU / powder coating
Drive & Control
• Lifting Mechanism: Hydraulic cylinder / wire rope hoist
• Motor & Gearbox: Electric drive system
• Control Panel: PLC / Relay-based
• Operation: Key switch / Push button
• Power Supply: 415V, 3 Phase, 50 Hz
Safety Features
• Electro-mechanical safety locking system
• Limit switches for accurate positioning
• Anti-fall & overload protection
• Emergency stop button
• Power failure safety locking
Vehicle Parameters
• Max Car Weight: Up to 2500 kg
• Max Car Width: Approx. 1900 mm
• Suitable Vehicles: Hatchback, Sedan, SUV
